MAIN SPECIFICATIONS

Provide the required size and specifications, we can provide customized services according to your needs. Originated from the global trailer production base, Shandong Liangshan. Preferential quotes, efficient services, reliable quality, can be stably and effectively guaranteed. No matter what type of product you need, you can contact us first.

Product Specification

Loading weight	50 tons
Size	1250025001500 mm
Axle	3 axle
Tare weight	7.5 tons
Axle brand	3* 13 tons axle
Tyre brand	12 units 12.00R22.5 tires,Triangle brand
Rims	6pcs* 11.75-22.5
Suspension System	3 axle with spring suspension
Brake System	Dual line pneumatic brake system,T30/30 air chamber; parking brake,WABCO relay valve
Under Frame	Main Beam is height 500mm; Q345B steel;14/16/8mm
Side beam	16# U-steel
Kingpin	2'or 3.5(90mm) interchangeable
Landing Gear	28tons heavy duty; 2 pieces;
Platform	3mm thick checkered plate
Front headboard	1.5m high
Twist locks	8 pies for 1x40ft container or 2x20ft containers
Electrical System	1. Voltage: 24v 2.Receptacle: 7 ways (7 wire harness); German standard
Lights/ Reflectors	LED; Rear light, rear reflector, turn indicativelight,side reflector, fog lamp, number plate light
Painting	As your request
Spare Tyre Carrier	One piece
Toolbox	One piece

Product Shows

1. Highly robust structure steel with tensile and high load capacity, 40 ton loading capacity.

3. Length and width of skeleton available custom made.

2. Heavy duty mechanical spring suspension for high loads requirements needs and handly bad road condition.

4. Air suspension and bogie suspension is an option. 8 units twist lock for carrying 20ft container and 40ft container.Product Specification
