New
Flatbed Trailer
  • ORENO
  • Shandong, China (Mainland)
  • 20-30days
  • 300 sets/month
Email
Message

MAIN SPECIFICATIONS

Provide the required size and specifications, we can provide customized services according to your needs. Originated from the global trailer production base, Shandong Liangshan. Preferential quotes, efficient services, reliable quality, can be stably and effectively guaranteed. No matter what type of product you need, you can contact us first.

Flatbed Container semi-trailer is specially used for the transportation of various containers 20FT 40FT, and it can also use its platform to transport ordinary bulk cargo.



The 40ft flatbed container trailer can carry 40ft and two 20ft containers. Flatbed trailer capacities range from 20 to 80 tons and are available in 2, 3 and 4 axles.


It is mainly used to transport various goods with unrestricted length, width and height, such as building materials, steel products and heavy machinery.



Customers can change the Flatbed Trailer's number of locks according to your own needs.


The size, color and logo of Flatbed Container Semi Trailer can be customized.


For example, we can customize Flatbed Container Trailer length to 45FT, 50FT, 55FT, 60FT, etc.



If you need more details for Flatbed Container Semi Trailer, please feel free to send us an inquiry.


Flatbed Semi Trailer Specification
20FT FLATBED SEMI TRAILER40FT FLATBED SEMI TRAILER45FT FLATBED SEMI TRAILER
2 Axles/3 Axles2 Axles/3 Axles /4 Axles3 Axles /4 Axles
20ft container or cargo loading1*40ft/2*20ft Container or cargo loading1*40ft/1*45ft container or cargo loading
Loading Capacity: 20 - 60 TonsLoading Capacity: 30 - 80 TonsLoading Capacity: 30 - 80 Tons
Gooseneck Type: YesGooseneck Type: YesGooseneck Type: Yes
Tandem Type: YesTandem Type: YesTandem Type: Yes
Main Beam
Material: Q345/T700Material: Q345/T700Material: Q345/T700
Upper Plate Thickness: 12mmUpper Plate Thickness: 16mmUpper Plate Thickness: 16mm
Middle Plate Thickness: 6mmMiddle Plate Thickness: 10mmMiddle Plate Thickness: 10mm
Lower Plate Thickness: 14mmLower Plate Thickness: 18mmLower Plate Thickness: 18mm
Height: 500mmHeight: 500mmHeight: 500mm
Platform Thickness: 2.5mmPlatform Thickness: 3mmPlatform Thickness: 3mm
Product Dimension
L 7000mm*W 2500mm*H 1570mmL 12400mm*W 2500mm*H 1570mmL 13950mm*W 2500mm*H 1600mm
Axles
2/3 Axles *13/16 Ton2/3 Axles *13/16 Ton2/3 Axles *13/16 Ton
ORENO/FUWA/BPW/OtherORENO/FUWA/BPW/OtherORENO/FUWA/BPW/Other
Tire
12R22.5 (8/12 Pieces)12R22.5 (8/12 Pieces)12R22.5 (8/12 Pieces)
Linglong/Triangle/Double-Coin/Bridgestone/Linglong/Triangle/Double-Coin/Bridgestone/Linglong/Triangle/Double-Coin/Bridgestone/
Other BrandOther BrandOther Brand
Rim
9.00*22.5 (8/12 Pieces) Steel/Aluminum9.00*22.5 (8/12 Pieces) Steel/Aluminum9.00*22.5 (8/12 Pieces) Steel/Aluminum
Leaf Spring
90mm*13mm*10/90mm*16mm*10Pcs90mm*13mm*10/90mm*16mm*10Pcs90mm*13mm*10/90mm*16mm*10Pcs
King Pin
50#(2")/90#(3.5") JOST/ORENO50#(2")/90#(3.5")   JOST/ORENO50#(2")/90#(3.5")   JOST/ORENO
Landing Gear
28 Ton Two Speed,JOST/Other Brand28 Ton Two Speed,JOST/Other Brand28 Ton Two Speed,JOST/Other Brand
Twist Lock
4 Sets12 Sets12 Sets
Vehicle Painting
Electrophoresis paintingElectrophoresis paintingElectrophoresis painting
